AR18/AR35 Series Single-Turn Absolute Encoders

24 July, 2020

2.492

Views0 Comments

Broadcom’s AR18 and AR35 series miniature programmable single-turn absolute encoders with resolution ranging from 17-bits to 21-bits

Broadcom’s AR18 and AR35 series are the miniature absolute encoder ASICs designed to cater to the growing demand for space-constrained applications. The AR18 encoder is designed for an overall diameter of 18 mm and offers user-programmable resolution ranging from 17-bit, 19-bit, and 21-bit single-turn absolute output. The AR35 encoder is designed for an overall diameter of 35 mm and offers 17-bit and 21-bit single-turn absolute output. Both the AR18 and AR35 series provide the incremental ABI and UVW in differential mode. Both come with a recommended temperature range of -40°C to +115°C suitable for most industrial applications. Dual-mode operating voltages of 3.3 V and 5 V enable handheld and portable device applications.

Features
Miniature absolute encoder ASIC surface mount DFN package: 10.9 mm (L) x 9.1 mm (W) x 1.5 mm (H) User-programmable resolution ranging from: 17-bit, 19-bit, and 21-bit single turn (OD18) 17-bit and 21-bit single turn (OD35) User-programmable incremental output (ABI) resolution ranging from 128 CPR to 8192 CPR Selectable SSI mode communication protocol RoHS-compliant	User-programmable commutation signal (UVW) in 2-pole, 3-pole, 4-pole, 5-pole, 12-pole, 30-pole, 32-pole pairs Differential output for ABI and UVW High temperature range of -40°C to +115°C suitable for most of the industrial operation Dual-mode operating voltage of 3.3 V and 5 V, enabling handheld and portable device applications Selectable RS485 mode communication protocol

more information: www.broadcom.com
