The project described here is a 10-minute timer using an Arduino microcontroller, capable of driving AC loads up to 30A. The timer's progress is visually represented by 10 LEDs, which light up sequentially, each for 1 minute, totaling 10 minutes. The project is powered by a single...

This simple Arduino compatible project reads an RC PWM signal (1000μs to 2000μs) and provides 0 to 500Hz pulse output to drive a stepper motor. Step and Direction outputs are open collector types 5V signals. Both signals can directly drive LEDs of optocoupler of stepper drivers. The...

This Bar-Graph Display provides a high visibility 15-Segment Bar-Graph display for current measurements. A buzzer provides audible sound when an over-current condition event occurs. The 15 segments are made with Red, Blue, Green, and yellow color LEDS. All LEDs are SMD size 1206. This...

This project consists of Arduino Arduino-compatible microcontroller ATmega328, an L298 Motor driver, a Joystick, a programming connector, an Infrared sensor, and various analog and digital I/O pins. The project is Arduino compatible and can be programmed using Arduino IDE and many...

This board consists of Arduino-compatible hardware which includes an OLED display, ADS1115 4-Channel 16Bit ADC, Arduino-compatible Microcontroller ATMEGA328, a connector for Arduino Programming, a connector for 4 Channel Analog input, and a connector for a couple of I/O lines....

This project allows users to monitor the liquid level on a Bar-Graph display. The liquid level is measured using a pressure sensor, the sensor is placed on top of the tank and is connected to an open-ended tube that is submerged in the water tank. The amount of water in the tank...

This is a compact, low-profile, and high-performance DC motor driver that provides easy control of a DC motor using a joystick. This small-size board can drive small to medium-sized brushed DC motors with up to 2.5A continuous and 6A peak currents. It is an Arduino-compatible project...

This is a pulse generator for a stepper motor driver using a joystick. It is a board that contains an Arduino-compatible microcontroller and circuitry for controlling up to 2-channel (2-axis) stepper motors. The board has multiple options to develop stepper motor-related control...
