This isolated power supply features the SN6507 chip, a push-pull isolation transformer driver, which provides a reliable and efficient power conversion solution. The power supply comprises a transformer, rectifier circuit, and isolation transformer T1, which separates the input and...

This is a fantastic project for makers, offering multiple output options of 3.3V, 5V, and 12V, with an input of 18-24V DC. This project is built around the MP2451 high-frequency (2Mhz) step-down switching regulator, ensuring efficient and reliable power conversion. For added...

The project presented here is an isolated flyback converter featuring the LT3748 chip from Analog Devices. The circuit is designed for a +/-340V DC (2 x 340V) output from a 7V to 15VDC input. The output current is up to 2 x 8mA. The board senses the isolated output voltage directly...

The project presented here is a low quiescent current, synchronous buck converter featuring the LTC3807. This DC-DC converts a 16V to 38V input voltage to a 12V at 6A output. The main features of this board include an internal LDO for gate drive power from VIN or EXTVCC, RUN pins, a...

The project presented here is a powerful constant-frequency, pulse-width modulating (PWM), current-mode step-up DC-DC switching regulator efficiently producing 5V from input voltages between 3V to 5V. The project can be used in a portable device that works with a battery. The module...

This is a low-cost DC-HV DC converter built using TL3843 Low-Power Current-Mode PWM Controller from TI. Screw terminal connectors are provided for input and output, onboard LED D1 indicates the input supply. The project provides 200V DC @ 20mA output from 12V DC supply...

This is a Phase-Shifted Full-Bridge PWM LM5046 carrier board that contains all of the features necessary to implement a phase-shifted full-bridge topology power converter. All inputs and outputs pins are accessible using the header connector. High efficiency DC-DC converter can be...

This is a step-down DC-DC converter mainly designed for application such as high-cell-count battery packs, power tools, garden tools and electric scooters, drones. Some of the features of the project is precision enable, input voltage UVLO, internal soft start etc. The project...
