STMicroelectronics TSC201x bidirectional current sense amplifier

STMicroelectronics TSC201x bidirectional current sense amplifier

The TSC2010, TSC2011, and TSC2012 are precision bidirectional current sense amplifiers.

The TSC2010, TSC2011, and TSC2012 are precision bidirectional current sense amplifiers. They can sense the current thanks to a shunt resistor over a wide range of common-mode voltages, from -20 to +70 V, whatever the supply voltage is. They are available with an amplifier gain of 20 V/V for TSC2010, 60 V/V for TSC2011, and 100 V/V for TSC2012.

They are able to sense very low drop voltages as low as 10 mV full scale minimizing the measurement error.

The TSC2010, TSC2011, and TSC2012 can also be used in other functions such as: precision current measurement, overcurrent protection, current monitoring, and feedback loops.

Key features

  • Wide common-mode voltage: -20 to 70 V
  • Offset voltage: ±200 µV max
  • 2.7 to 5.5 V supply voltage
  • Different gain options available – TSC2010: 20 V/V – TSC2011: 60 V/V – TSC2012: 100 V/V

Additional features

  • Wide common-mode voltage:
    • From -20 to +70 V
  • Offset voltage: ±200 µV max
  • 2.7 to 5.5 V supply voltage
  • Different gain options available:
    • TSC2010: 20 V/V
    • TSC2011: 60 V/V
    • TSC2012: 100 V/V
  • Gain error: 0.3% max
  • Offset drift: 5 µV/°C max
  • Low quiescent current:
    • 20 µA in shutdown mode
  • SO-8 and MiniSO-8 package

more information: https://www.st.com/en/amplifiers-and-comparators/tsc2010.html
